AES Battery Design Philosophy
We examine the key considerations in the design of our LITHIUM AES batteries and what sets them apart from our competitors.
Work Vehicle Batteries
Work Vehicle Lithium Batteries
AES LiFePO4 Designed to integrate with the world’s best work vehicle inverter charger systems, the AES LiFePO4 BMS delivers superior peak power and a fast 1C charge rate. LYNK Port connects a LYNK Gateway to communicate real-time SoC and set voltage as well as temperature parameters with the system.
AES PROFESSIONAL AES PROFESSIONAL batteries feature self-heating and a proprietary high current battery management system. Trusted OEM quality, tested and certified to the highest safety and performance standards, the AES PROFESSIONAL Series is lightweight and purpose-built to replace standard BCI 6V, 8V and 12V sizes. AES PROFESSIONAL Series has LYNK Gateway options for systems integration.
AES BLUE Designed for excellence, AES BLUE batteries for house power loads offer BMS controlled safety, long life, lightning-fast charging performance and real-time Bluetooth access to battery State of Charge, voltage, current, and temperature status.
AES Key Benefits
- 2x the high-current runtime of lead-acid battery
- 100% usable capacity
- Up to 5x faster charging than new lead-acid batteries
- 2x faster charging than C/2 lithium batteries
- 10x the life of a lead-acid battery
- Plug and play inverter charger configuration**
- Up to 3C peak power for inverter surge demand
- UL 1973 safety certified
- Maintenance-free
*BCI-06
- Up to double the runtime of a lead-acid battery
- 100% usable capacity
- 100% Depth of Discharge
- 10x the life of a lead-acid battery (BCI-06)
- 7-year energy throughput warranty
- Up to 5x faster than new lead-acid batteries
- Up to 10x faster than aged lead-acid batteries
- 2x faster than C/2 rated lithium batteries
- 1C opportunity charge anytime, regardless of SoC
- Power for traction motors
- Up to 3C peak power discharge rate
- 1C continuous discharge rate
- Up to 50% more energy efficient than a lead-acid battery
- Up to 98% round-trip efficiency
- Real-time optimization of the charge rate up to 25%
- Faster recharge from 0% to 100% SoC
- Easy to parallel more capacity
- Linear scaling of charge, discharge, and peak capacity
- Parallel up to 20 batteries per LYNK device
- Fast install. No special tools
- Drop-in deep-cycle lead-acid replacement
- LiFePO4 is thermally safe
- Maintenance-free steel case and cover
- IP 55 rated
- Connects battery string to LYNK gateway
- Multi-battery BMS communication
The AES LiFePO4 Mobile Industrial Advantage
AES LiFePO4 batteries deliver productivity gains through enhanced cycling, charge time, and weight reductions in mobile applications.
Purpose-built OEM battery with a proprietary high current BMS, extreme temperature operation, and LYNK Gateway functionality for system component integration.
Find Your Battery
Accessories
CAN Bus Battery Discharge Indicator (Type A) 950-0044
COMPATIBILITY:
AES LiFePO4 batteries: 12-48-6650, 12-36-6700, 14-24-2800, 14-36-3000, 14-48-3000
AES PROFESSIONAL batteries: DLP-GC2-12V, DLP-GC2-24V, DLP-GC2-36V, DLP-GC2-48V
The 950-0044 is a fully featured Battery Discharge Indicator (BDI) that communicated with AES LiFePO4 Mobile Industrial and AES PROFESSIONAL batteries and presents visualization by LCD of the battery's State of Charge, Voltage, Power, Charge and Discharge Energy, Battery Firmware, and Time to Go.
CAN Bus Battery Discharge Indicator (Type B) 950-0039
COMPATIBILITY:
AES LiFePO4 batteries: 12-48-6650, 12-36-6700, 14-24-2800, 14-36-3000, 14-48-3000
AES PROFESSIONAL batteries: DLP-GC2-12V, DLP-GC2-24V, DLP-GC2-36V, DLP-GC2-48V
The 950-0039 is a Battery Discharge Indicator (BDI) that communicates with AES LiFePO4 Mobile Industrial and AES PROFESSIONAL batteries presenting the battery's state of charge by incremental LED segments.
LYNK LITE Communication Gateway
LYNK LITE Communication Gateway aggregates and displays the State of Charge for AES LiFePO4 batteries in a compact package suitable for in-line integration in motive machine battery compartments.
LYNK II
Advanced Integration - Faster Charging
Unlock the full potential of a AES LiFePO4 Mobile Industrial battery by enabling the BMS to optimize and dynamically manage the charge configurations of the world's best industrial chargers and mobile inverter chargers. The LYNK PORT on each AES LiFePO4 allows for real-time closed-loop communication between multiple batteries and with a charger, or inverter charger, using LYNK II to aggregate and communicate State of Charge.
Additional Accessories
Optional networking accessories are available with AES LiFePO4.
- DLP B2B-400 (COMM Cable 0.4 meters / 15.75 inches) | PN: 950-0035
- DLP TOL-7600 (COMM Cable 7.6 meters / 299.25 inches) | PN: 950-0037
- DLP TOL-1800 (COMM Cable 1.8 meters / 70.87 inches) | PN: 950-0036
- DLPT Connector (COMM T Connector) | PN: 950-0041
- DLP T Connector (COMM T Connector) with DLP B2B-400 (COMM Cable 0.4 meters / 15.75 inches) | PN: 950-0038
AES PROFESSIONAL
Key Benefits
10X The Life Of Lead-Acid Batteries*
- Up to 2x the runtime of a lead-acid battery
- 100% usable capacity
- Lightning fast charging
- Integrated self-heating
- Communicates SoC, voltage and temperature limits with charger**
- Port connects the battery to LYNK Gateway
- Field replaceable fuse protection
- Parallel more capacity - up to 20 batteries**
- IP 67 rated
- Maintenance-free
*BCI-06
** LYNK Gateway
- Exceeds OEM quality requirements
- Global service and support
- Innovative technology
- Optimized for start-stop vehicles
- Partial state-of-charge operation
- Micro-cycling and key-off loads
- Up to 5x faster than new lead-acid batteries
- Up to 10x faster than aged lead-acid batteries
- 2x faster than C/2 rated lithium batteries
- Opportunity charge at 1C rate anytime, regardless of SoC
- Surge power for inverters and traction motors
- Up to 3C peak power discharge rate
- 1C continuous discharge rate
- Up to 50% more energy efficient than a lead-acid battery
- Up to 98% round-trip efficiency
- Real-time optimization of the charge rate
- Up to 25% faster recharge from 0% to 100% SoC
- Easy to parallel more capacity
- Linear scaling of charge, discharge, and peak capacity
- Parallel up to 20 batteries per LYNK device
- Fast install. No special tools
- Drop-in deep-cycle lead-acid replacement
- LiFePO4 is safe
- Maintenance-free
- UL94 VO flame retarding case and cover
- IP 67 rated
- Connects battery string to LYNK gateway
- Multi-battery BMS communication
- At-a-glance multi-color status LED
- Integrated self-heating
- Charging from -20oC/-4oC
The AES PROFESSIONAL Advantage
Purpose-built OEM battery with a proprietary high-current BMS, extreme temperature operation, and LYNK gateway functionality for system component integration.
Find Your Battery
AES PROFESSIONAL Accessories
CAN Bus Battery Discharge Indicator (Type A) 950-0044
COMPATIBILITY:
AES LiFePO4 batteries: 12-48-6650, 12-36-6700, 14-24-2800, 14-36-3000, 14-48-3000
AES PROFESSIONAL batteries: DLP-GC2-12V, DLP-GC2-24V, DLP-GC2-36V, DLP-GC2-48V
DLP-E batteries: DLP-E-24V, DLP-E-48V
The 950-0044 is a fully featured Battery Discharge Indicator (BDI) that communicated with AES LiFePO4 Mobile Industrial and AES PROFESSIONAL batteries and presents visualization by LCD of the battery's State of Charge, Voltage, Power, Charge and Discharge Energy, Battery Firmware, and Time to Go.
950-0044 - Bundled with cable
950-0006 - Without cable
CAN Bus Battery Discharge Indicator (Type B) 950-0039
COMPATIBILITY:
AES LiFePO4 batteries: 12-48-6650, 12-36-6700, 14-24-2800, 14-36-3000, 14-48-3000
AES PROFESSIONAL batteries: DLP-GC2-12V, DLP-GC2-24V, DLP-GC2-36V, DLP-GC2-48V
DLP-E batteries: DLP-E-24V, DLP-E-48V
The 950-0039 is a Battery Discharge Indicator (BDI) that communicates with AES LiFePO4 Mobile Industrial and AES PROFESSIONAL batteries presenting the battery's state of charge by incremental LED segments.
950-0039 - Bundled with cable
950-0034 - Without cable
LYNK LITE Communication Gateway
LYNK LITE Communication Gateway aggregates and displays the State of Charge for AES PROFESSIONAL batteries in a compact package suitable for in-line integration in motive machine battery compartments.
LYNK II
ADVANCED INTEGRATION - FASTER CHARGING
Unlock the full potential of an AES PROFESSIONAL Battery by enabling the BMS to optimize and dynamically manage the charge configurations of the world’s best industrial chargers and mobile inverter-chargers. The LYNK PORT on each AES PROFESSIONAL battery allows for real-time closed-loop communication between multiple batteries and with a charger, or inverter-charger, using LYNK II to aggregate and communicate State of Charge..
Additional Accessories
IP-65 rated network cables suitable for wet and humid environments are available for IP-67 rated AES PROFESSIONAL batteries.
- DLP B2B-400 (COMM Cable 0.4 meters / 15.75 inches) | PN: 950-0035
- DLP TOL-7600 (COMM Cable 7.6 meters / 299.25 inches) | PN: 950-0037
- DLP TOL-1800 (COMM Cable 1.8 meters / 70.87 inches) | PN: 950-0036
- DLPT Connector (COMM T Connector) | PN: 950-0041
- DLP T Connector (COMM T Connector) with DLP B2B-400 (COMM Cable 0.4 meters / 15.75 inches) | PN: 950-0038
AES BLUE Benefits and Features
AES BLUE batteries charge faster, last longer, run longer, and are lighter weight than traditional lead-acid batteries. They have a carry handle, are easy to install, require no special tools, and feature a user-replaceable fuse.
AES BLUE Key Benefits
- Up to 2x the runtime of lead-acid battery
- 100% usable capacity
- Lightning fast charging
- 10x the life of a lead-acid battery*
- Easy to install and parallel for more capacity
- Terminal protection and field serviceable fuses
- IP 67 rated
*BCI-06
- Exceeds OEM quality requirements
- Global service and support
- Innovative technology
- Optimized for start-stop vehicles
- Partial state of charge operation
- Micro-cycling and key-off loads
- Up to 5x faster than new lead-acid batteries
- Up to 10x faster than aged lead-acid batteries
- 2x faster than C/2 rated lithium batteries
- Opportunity charge at 1C rate anytime, regardless of SoC
- Surge power for inverters and traction motors
- Up to 3C peak power discharge rate
- 1C continuous discharge rate
- Up to 50% more energy efficient than a lead-acid battery
- Up to 98% round-trip efficiency
- Easy to parallel more capacity
- Linear scaling of charge, discharge, and peak capacity
- Parallel up to 20 batteries per LYNK device
- Fast install. No special tools
- Drop-in deep-cycle lead-acid replacement
- LiFePO4 is safe
- Maintenance-free
- UL94 VO flame-retarding case and cover
- IP 67 rated
- State of charge
- Voltage/current
- Tempertature oF/oC
AES BLUE FAQs
No. There are no special tools required to install AES BLUE. Tools are the same as for the installation of a deep-cycle lead-acid battery. If you can install a deep-cycle lead-acid battery, you can install AES BLUE.
Yes. AES BLUE features thermally safe and long-life Lithium Iron Phosphate (LiFePO4) cells. AES BLUE is also IP 67 rated and suitable for applications in humid and wet environments.
